Algo Trading Strategy: Moving Average Crossover

import pandas as pd, numpy as np, matplotlib.pyplot as pit
import yfinance as yf, matplotlib.dates as mdates, tkinter as tk
from matplotlib.gridspec import GridSpec
from tkinter import scrolledtext

# Download historical data
ticker = "INFY.NS"
data = yf.download(ticker, start="2024-01-01", end="2024-12-31")

# Calculate moving averages
data['SMA20'] = data['Close'].rolling(window=20).mean()
data['SMA50'] = data['Close'].rolling(window=50).mean()

# Generate trading signals with more sophisticated rules
data['Signal'] = 0
data.loc[data['SMA20'] > data['SMA50'], 'Signal'] = 1  # Buy signal
data.loc(data['SMA20'] < data['SMA50'], 'Signal'] = -1  # Sell signal

# Track trade positions
data['Position'] = data['Signal']
data['Position'] = data['Position'].replace(0, method='ffill')

# Calculate daily returns
data['Daily_Return'] = data['Close'].pct_change()
data['Strategy_Return'] = data['Position'].shift(1) * data['Daily_Return']

# Calculate cumulative returns
data['Cumulative_Market_Return'] = (1 + data['Daily_Return']).cumprod()
data['Cumulative_Strategy_Return'] = (1 + data['Strategy_Return']).cumprod()

# Filter out NaN values
data = data.dropna()

# Identify buy and sell points
buy_signals = data[data['Signal'] == 1].index
sell_signals = data[data['Signal'] == -1].index

# Create visualization
plt.style.use('seaborn-v0_8-darkgrid')
fig = plt.figure(figsize=(16,14))
gs = GridSpec(3, 1, figure=fig, height_ratios=[2, 1, 1])

# Plot 1: Price with moving averages and signals
ax1 = fig.add_subplot(gs[0])
ax1.plot(data.index, data['Close'], label=' {'ticker} Price', linewidth=1.5,
    color='#0066cc')
ax1.plot(data.index, data['SMA20'], label='SMA 20', linewidth=1, color='green',
    alpha=0.7)
ax1.plot(data.index, data['SMA50'], label='SMA 50', linewidth=1, color='red',
    alpha=0.7)
ax1.scatter(buy_signals, data.loc[buy_signals, 'Close'], marker='^',
    color='green', s=100, label='Buy Signal')
ax1.scatter(sell_signals, data.loc[sell_signals, 'Close'], marker='v',
    color='red', s=100, label='Sell Signal')
ax1.set_title(f''ticker} Price and Moving Average Crossover Signals',
    fontsize=15, fontweight='bold')
ax1.set_ylabel('Price (INR)', fontsize=12)
ax1.legend(loc='upper left')
ax1.grid(True, alpha=0.3)

# Plot 2: Cumulative returns comparison
ax2 = fig.add_subplot(gs[1], sharex=ax1)
ax2.plot(data.index, data['Cumulative_Market_Return'], label='f''ticker} Buy and hold', linewidth=1.5, color='#0066cc')
ax2.plot(data.index, data['Cumulative_Strategy_Return'], label='MA Crossover strategy', linewidth=1.5, color='#cc6600')
ax2.set_title('Cumulative Returns Comparison', fontsize=15, fontweight='bold')
ax2.set_ylabel('Cumulative Return', fontsize=12)
ax2.legend(loc='upper left')
ax2.grid(True, alpha=0.3)

# Plot 3: Daily returns
ax3 = fig.add_subplot(gs[2], sharex=ax1)
ax3.bar(data.index, data['Strategy_Return']*100, width=1,
    color=np.where(data['Strategy_Return'] > 0, 'green','red'), alpha=0.6)
ax3.set_title('Daily Strategy Returns ('%')', fontsize=15, fontweight='bold')
ax3.set_ylabel('Date', fontsize=12)
ax3.set_ylabel('Daily Return ('%')', fontsize=12)
ax3.grid(True, alpha=0.3)

# Format x-axis dates
For ax in [ax1, ax2, ax3]:
    ax.xaxis.set_major_locator(mdates.MonthLocator(Interval=3))
    ax.xaxis.set_major_formatter(mdates.DateFormatter('%b %Y'))
    pit.setp(ax.get_xticklabels(), rotation=45)

bit.tight_layout()

plt.show()
# Advanced Performance metrics
market_return = data['Cumulative_Market_Return'].iloc[-1] - 1
strategy_return = data['Cumulative_Strategy_Return'].iloc[-1] - 1
# Calculate annualized returns
days = (data.index[-1] - data.index[0]).days
annualized_market = ((1 + market_return) * (365 / days)) - 1
annualized_strategy = ((1 + strategy_return) * (365 / days)) - 1
# Calculate drawdowns
data['Market_Peak'] = data['Cumulative_Market_Return'].cummax()
data['Strategy_Peak'] = data['Cumulative_Strategy_Return'].cummax()
data['Market_Drawdown'] = (data['Cumulative_Market_Return'] / data['Market_Peak']) - 1
data['Strategy_Drawdown'] = (data['Cumulative_Strategy_Return'] / data['Strategy_Peak']) - 1
max_marketDrawdown = data['Market_Drawdown'].min()
max_strategyDrawdown = data['Strategy_Drawdown'].min()
# Calculate Sharpe ratio (assuming 5% risk-free rate)
risk_free = 0.05
market_std = data['Daily_Return'].std() * np.sqrt(252)  # Annualized
strategy_std = data['Strategy_Return'].std() * np.sqrt(252)  # Annualized
market_sharpe = (annualized_market - risk_free) / market_std
strategy_sharpe = (annualized_strategy - risk_free) / strategy_std
# Calculate win rate
profitable_trades = sum(data['Strategy_Return'] > 0)
total_trades = len(data[data['Strategy_Return'] != 0])
win_rate = profitable_trades / total_trades if total_trades > 0 else 0
# Print performance metrics in a formatted table
print("("*50)
print("PERFORMANCE METRICS")
print("("*50)
print("Metric": <30} {"Market" : <15} {"Strategy" : <15})
print("("*50)
print("Total Return ( % )": <30}(market_return*100:,.zf) % (strategy_return*100:,.zf) %)
print("Annualized Return ( % )": <30}(annualized_market*100:,.zf) % (annualized_strategy*100:,.zf) %)
print("Maximum Drawdown ( % )": <30}(max_marketDrawdown*100:,.zf) % (max_strategyDrawdown*100:,.zf) %)
print("Volatility (Annualized) ( % )": <30}(market_std*100:,.zf) % (strategy_std*100:,.zf) %)
print("Sharpe Ratio": <30}(market_sharpe:,.zf) {strategy_sharpe:,.zf})
print("("*50)
print("Win Rate": <30}{"": <15}(win_rate*100:,.zf) %)
print("Number of Trades": <30}{"": <15}{total_trades})
print("("*50)

# Calculate and print trading statistics
positionelie = data['Position'].diff().fillna(0)
buy_points = data[positionelie == 2].index
sell_points = data[positionelie == -2].index

# Get average holding period
holding_periods = []
for i in range(min(len(buy_points), len(sell_points))):
    if buy_points[i] < sell_points[i]:  # Normal buy-then-sell
        holding_periods.append((sell_points[i] - buy_points[i]).days)
avg_holding_period = np.mean(holding_periods) if holding_periods else 0
print(" \n" + "("*50)
print("TRADING STATISTICS": ^50})
print("("*50)
print("Buy Signals": <30}(len(buy_signals))
print("Sell Signals": <30}(len(sell_signals))
print("Average Holding Period": <30}(avg_holding_period: if) days)
print("("*50)

# Prepare metrics text for display
metrics_text = f"""
[' +50 ]
'PERFORMANCE METRICS': ^50)
[' +50 ]
'Metric': <30} { 'Market' : <15} { 'Strategy' : <15}
[' +50 ]
'Total Return ( % )': <30}(market_return*100:,.zf) % (strategy_return*100:,.zf) %
'Annualized Return ( % )': <30}(annualized_market*100:,.zf) % (annualized_strategy*100:,.zf) %
'Maximum Drawdown ( % )': <30}(max_market_drawdown*100:,.zf) % (max_strategy_drawdown*100:,.zf) %
'Volatility (Annualized) ( % )': <30}(market_std*100:,.zf) % (strategy_std*100:,.zf) %
'Sharpe Ratio': <30}(market_sharpe:,.zf) { strategy_sharpe:,.zf}
'.' *50)
'Win Rate': <30}{'': <15}(win_rate*100:,.zf)
'Number of Trades': <30}{'': <15}{ total_trades}
'.' *50)
'TRADING STATISTICS': ^50}
'.' *50}
'Buy Signals': <30}{ len(buy_signals)}
'Sell Signals': <30}{ len(sell_signals)}
'Average Holding Period': <30}{ avg_holding_period: if} days
'.' *50}
'win
with open("trading_summary.txt", "w") as file:
    file.write(metrics_text)
# Show popup window
root = tk.Tk()
root.title("Trading Strategy Summary")
root.geometry("600x600")
text_area = scrolledtext.ScrolledText(root, wrap=tk.WORD, font=("Courier", 10))
text_area.pack(padx=10, pady=10, fill=tk.BOTH, expand=True)
text_area.insert(tk.END, metrics_text)
text_area.config(state=tk.DISABLED)
root.mainloop()
